6,350₾
The ECOBSS FLEX 3L is a three-phase hybrid inverter differentiated by firmware—not raw kW—shipping with PowerWallet EMS that unifies daily buy, sell, and auto-consumption schedules stock Deye units cannot express without manual 'Selling First' toggles.
| Parameter | FLEX 3L6K | FLEX 3L8K | FLEX 3L10K | FLEX 3L12K |
|---|---|---|---|---|
| Battery Input Data | ||||
| Battery Type | Lead-acid or LiFePO4 | |||
| Battery Voltage Range (V) | 40-60 | |||
| Max. Charging Current (A) | 120 | 160 | 200 | 240 |
| Max. Discharging Current (A) | 120 | 160 | 200 | 240 |
| External Temperature Sensor | Yes | |||
| Charging Curve | Three-stage | |||
| Charging Strategy for Li-ion Battery | Self-adaption to BMS | |||
| PV String Input Data | ||||
| Max. PV Access Power (W) | 7800 | 10400 | 13000 | 15600 |
| Rated PV Input Voltage (V) | 550 (160-800) | |||
| Start-up Voltage (V) | 160 | |||
| MPPT Voltage Range (V) | 200-650 | |||
| Full MPPT Voltage Range (V) | 350-650 | |||
| Max. Operating PV Input Current (A) | 13+13 | 26+13 | ||
| Max. Input Short-Circuit Current (A) | 17+17 | 34+17 | ||
| No. of MPP Trackers / No. of Strings per MPP Tracker | 2/2+1 | |||
| AC Input/Output Data | ||||
| Rated AC Input/Output Active Power (W) | 6000 | 8000 | 10000 | 12000 |
| Max. AC Input/Output Apparent Power (VA) | 6600 | 6800 | 11000 | 13200 |
| Rated AC Input/Output Current (A) | 9.1/8.7 | 12.1/11.6 | 15.2/14.5 | 18.2/17.4 |
| Max. AC Input/Output Current (A) | 10/9.6 | 13.4/12.8 | 16.7/15.9 | 20/19.1 |
| Max. AC Output Short-Circuit Current (A) | 75 | |||
| Max. Continuous AC Passthrough (grid to load) (A) | 45 | |||
| Peak Power (off-grid) (W) | 2 times of rated power, 10s | |||
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging | |||
| Rated Input/Output Grid Frequency/Range (Hz) | 50/60Hz | |||
| Rated Input/Output Voltage/Range (V) | 3L/N+PE 220/380Vac, 230/400Vac | |||
| Grid Type | Three-phase | |||
| Total Current Harmonic Distortion THDi | <3% | |||
| Efficiency | ||||
| Max. Efficiency | 97.6% | |||
| Euro Efficiency | 97.0% | |||
| MPPT Efficiency | 99.0% | |||
| Equipment Protection | ||||
| Integrated Protections | Anti-islanding Protection DC Reverse Polarity Protection Insulation Impedance Detection Residual Current Detection AC Output Overcurrent Protection AC Output Short Circuit Protection |
|||
| Surge Protection Level | TYPE III(DC), TYPE III(AC) | |||
| Over Voltage Category | OVC II(DC), OVC III(AC) | |||
| Interface | ||||
| BMS Communication Interface | RS485, CAN | |||
| Monitor Mode | Wi-Fi + App | |||
| General Data | ||||
| Operating Temperature Range (°C) | -40 to +60°C, >45°C Derating | |||
| Type of Cooling | Smart active cooling | |||
| Noise | <70 dB / 60 dBA (silent mode) | |||
| Ingress Protection (IP) Rating | IP65 | |||
| Mounting Type | Wall mount | |||
| Cabinet Size (W×H×D mm) | 446×576×255 (Excluding Connectors and Brackets) | |||
| Weight (kg) | 37.5 | |||
| Grid Regulation | IEC 61727, IEC 62116, EN 50549-1 | |||
| Safety / EMC Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |||
See the datasheet (PDF) for the full specification.
Architected for 51.2 V ECOBSS STORE energy storage stacks (L5/L10/L15), FLEX 3L targets installers who sell integrated EcoBSS ecosystems: inverter + STORE modules + cloud EMS in one commissioning workflow. CAN BMS mapping follows EcoBSS conventions; mixing arbitrary third-party 51.2 V blocks requires explicit compatibility approval—default designs use STORE series only.
PowerWallet enables tariff-aware dispatch against Georgian B2B (0.35 ₾/kWh) and B2C (0.24 ₾/kWh) profiles: charge overnight on cheap windows, discharge at peak, export when permitted—all within one daily schedule table. This reduces custom SCADA for hotels and retail chains that otherwise bolt external EMS onto Deye hardware.
Hardware parallels other 6–12 kW three-phase hybrids: MPPT PV inputs, grid backup transfer, export limiting, and App visibility. GEN-port AC Coupling may be supported per firmware revision—confirm in EcoBSS release notes before promising retrofit topology identical to Deye LP3.
